●5.5-inch Transmitter x 1
●M8 Motor Set x 4 set (Max. Tensile Force: 12kg/set)
●AP6 Flight Control x 1
●G3P 4K Tri-axis Gimbal x 1
●GNSS module with helical antenna x 1
●Front Obstacle Avoidance Radar x 1
●Millimeter Wave Radar x 1
●Ground Station App (with built-in Exam Mode for Android system)
●Enhanced Control Hook x 1(Max. Tensile Force: 20kg)
●6S 10000mAh Intelligent Battery x 2
●1200W Dual-Channel Intelligent Charger x 1
●Recommended Battery：12S (LiPo)
●External Diameter：70mm
●KV Value : 180KV
●Weight：720g
●Working Environment Temperature : -20~50℃
RM41004XW ALIGN M4PS Mission Drone
Focus Shots
Standard Equipment
●M4PS Mission Drone Kit Set x 1●5.5-inch Transmitter x 1
●M8 Motor Set x 4 set (Max. Tensile Force: 12kg/set)
●AP6 Flight Control x 1
●G3P 4K Tri-axis Gimbal x 1
●GNSS module with helical antenna x 1
●Front Obstacle Avoidance Radar x 1
●Millimeter Wave Radar x 1
●Ground Station App (with built-in Exam Mode for Android system)
●Enhanced Control Hook x 1(Max. Tensile Force: 20kg)
●6S 10000mAh Intelligent Battery x 2
●1200W Dual-Channel Intelligent Charger x 1
ALIGN M4PS Product Specification
Airframe: 1080mm
Height: 421mm
Foldable Rotor: 23 Inch
Main Rotor Diameter: 585mm
Power System: M8 Motor Set x 4 set (Max. Tensile Force: 12 kg/set)
Empty Weight: 6 kg
Load Capacity: 10Kg
Flying weight: 8.8Kg (including battery 12S 10000mAh)
Flying weight: 10.2Kg (including battery 12S 16000mAh)
Max. Takeoff Weight: 22.4 kg
Flight Time without payload:
- Approx. 28min (no load and using 12S 10000mAh)
- Approx. 35min (no load and using 12S 16000mAh)
- Approx. 43min (no load and using 12S 22000mAh)
Positioning Precision: PositionAccuracy within 1 meter
(Affected by Satellite Conditions)
Max. Radio Control Distance:
2.5~3KM (w/o interference and/or obstacle)
Height: 421mm
Foldable Rotor: 23 Inch
Main Rotor Diameter: 585mm
Power System: M8 Motor Set x 4 set (Max. Tensile Force: 12 kg/set)
Empty Weight: 6 kg
Load Capacity: 10Kg
Flying weight: 8.8Kg (including battery 12S 10000mAh)
Flying weight: 10.2Kg (including battery 12S 16000mAh)
Max. Takeoff Weight: 22.4 kg
Flight Time without payload:
- Approx. 28min (no load and using 12S 10000mAh)
- Approx. 35min (no load and using 12S 16000mAh)
- Approx. 43min (no load and using 12S 22000mAh)
Positioning Precision: PositionAccuracy within 1 meter
(Affected by Satellite Conditions)
Max. Radio Control Distance:
2.5~3KM (w/o interference and/or obstacle)
ALIGN M4PS Specification
M8 Motor Power Set Specification
●Max. Tensile Force : 12kg/Set(48V)●Recommended Battery：12S (LiPo)
●External Diameter：70mm
●KV Value : 180KV
●Weight：720g
●Working Environment Temperature : -20~50℃
Flight Safety
