HW30203201 HOBBYWING PLATINUM-80A-V5

$168.99 AUD
SKU: HW30203201
← Previous Product Next Product →

HOBBYWING PLATINUM-80A-V5: A Game-Changer for RC Enthusiasts

Product Name
  Platinum 80A V5
Product Number
  30203201
Type
Brushed/Brushless BL
High Voltage/Regular Regular
Specifications
Cont./Peak Current 80A/120A
Input Voltage 3-8S Lipo
BEC Output Switch Mode：5-12V & Cont. 8A，Peak 20A
Wires & Connectors
Input Wires Red-12AWG-100mm*1/Black-12AWG-100mm*1
Output Wires Black-14AWG-100mm*3
Input Connectors No
Output Connecotors 3.5mm Gold Connectors (Female)
ESC Programing via
Transmitter Not Support
LED Program Card Not Support
LED Program Box Not Support
LCD Program Box Supported
OTA Programmer Supported
Program Port Separate Program Port
Firmware
Firmware Upgrade Supported
Telemetry Function
  Mikado VBar；Futaba S.Bus2；etc.
Size & Weight
Size 60.5*33*17.6mm (without fan)
Weight 77.5g (with wires, no fan)
Application scope
  325-420 class electric helicopter (main blade length 325-420mm),or fixed-wing

(HW30203201)
